LEESON 048A11O1524 X213 / 48A11O1524C Condenser Fan Motor, 0.25 HP, 1 Phase, 60 Hz, 208-230V, 1200 RPM
Get it by Tuesday, Oct 1
€68.59 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 60 |
| Assembly | F1 ONLY |
| Duty | CONTINUOUS AOM |
| Efficiency | 66 % |
| Enclosure | OPAO |
| Frame | 48Z |
| Full Load Amps | 1.4-1.2 |
| HP | 1/4 |
| Hz | 60 |
| Insulation Class | B |
| kW | 0.187 |
| Mounting | Extended Studs - Footless |
| NEMA Design | NO DESIGN CODE |
| Orientation | SHAFT UP |
| Phase | 1 |
| Rotation | SELECTIVE CCW |
| RPM | 1075 |
| Service Factor | 1.0 |
| Thermal Protection | Automatic Protector (under locked rotor only) |
| Voltage | 208-230 |
| Ship weight (kg) | 5.4 |
| Ship height (cm) | 17.63 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 17.78 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Duty | Enclosure | Frame | Full Load Amps | HP | kW | Orientation | Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048A11O678 | CONT.AOM | OPAO | 48Y | 5.1 | 3/4 | 0.56 | Horizontal | SELECTIVE CCW | €103.89 | |
 |
048A11O2017 | CONTINUOUS AOM | OPAO | 48Z | 1.4 | 1/2 | 0.37 | Horizontal | SELECTIVE CCW | €364.84 | |
 |
5KCP49ZN9617T | Continuous | Open | 56Z | 6.7-6.8/3.4 | 1 | - | Vertical Shaft Up | Select Counter clockwise | €777.94 | |
 |
048A11O1771 | CONT.AOM | OPAO | 48Y | 1.15 | 1/2 | 0.37 | Horizontal | SELECTIVE CCW | €98.52 | |
 |
048A11O2016 | CONT.AOM | OPAO | 48Y | 2.5 | 3/4 | 0.56 | Horizontal | SELECTIVE CCW | €385.62 | |
 |
048A11O2054 | CONT.AOM | OPAO | 48Y | 1.4 | 1/3 | 0.25 | Horizontal | SELECTIVE CCW | €85.57 | |
 |
048A17O172 | CONT.AOM | OPAO | 48Y | 1.7 | 1/2 | 0.37 | Horizontal | SELECTIVE CCW | €406.99 |
