LEESON 048C17D2043 B314 / 48C17D2043L Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 115/208-230V, 1800 RPM
Get it by Tuesday, Oct 1
€374.00 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 40 |
| Assembly | F1 ONLY |
| Duty | Continuous |
| Efficiency | N/A % |
| Enclosure | DP |
| Frame | 48Z |
| Full Load Amps | 5.8/3.1-2.9 |
| HP | 1/3 |
| Hz | 60 |
| Insulation Class | B |
| kW | 0.25 |
| Mounting | Resilient Rings - Extended Studs |
| NEMA Design | DEFINITE DUTY |
| Orientation | Horizontal |
| Phase | 1 |
| Rotation | SELECTIVE CCW |
| RPM | 1800 |
| Service Factor | 1.35 |
| Voltage | 115/208-230 |
| Ship weight (kg) | 8.1 |
| Ship height (cm) | 20.47 |
| Ship length (cm) | 31.6 |
| Ship width (cm) | 23.19 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Length Less Shaft | Motor Thermal Protection | Mounting | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR48TN3084X | 56H | 5.3-5.4/3.6-3.7 | 1, 1/3 | 50/60 | - | 10 11/16" | Auto | Cradle Base | €999.78 | |
 |
5KCR49PN3011 | 56 | 9.0/6.4 | 3/4, 1/4 | 60 | - | 9.625" | Auto | Cradle Base | €757.16 | |
 |
5KCR49PN3011X | 56 | 9.0/6.4 | 3/4, 1/4 | 60 | - | 9.625" | None | Cradle Base | €889.17 | |
 |
5KCR49PN3012X | 56 | 4.3-4.4/3.1-3.2 | 3/4, 1/4 | 60 | - | 9.625" | Auto | Cradle Base | €769.38 | |
 |
5KCR49SN3009 | 56 | 10.8/7.4 | 1, 1/3 | 60 | - | 10.125" | None | Cradle Base | €942.34 | |
 |
5KCR49SN3009X | 56 | 10.8/7.4 | 1, 1/3 | 60 | - | 10.125" | Auto | Cradle Base | €980.84 | |
 |
056C17D2074 | 56 | 10.0/5.2-5.0 | 3/4 | 60 | 0.56 | - | - | Resilient Base - Extended Studs | €395.72 |
