LEESON 048S17D2086 D143 / 48S17D2086R Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Tuesday, Oct 1
€247.51 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 40 |
| Assembly | F1 ONLY |
| Duty | Continuous |
| Efficiency | 62 % |
| Enclosure | DP |
| Frame | 48 |
| Full Load Amps | 6.1 |
| HP | 1/3 |
| Hz | 60 |
| Insulation Class | B |
| kW | 0.25 |
| Mounting | Resilient Base |
| NEMA Design | NO DESIGN CODE |
| Orientation | Horizontal |
| Phase | 1 |
| Rotation | SELECTIVE CCW |
| RPM | 1800 |
| Service Factor | 1.35 |
| Thermal Protection | Automatic Protector |
| Voltage | 115 |
| Ship weight (kg) | 6.75 |
| Ship height (cm) | 16.81 |
| Ship length (cm) | 28.09 |
| Ship width (cm) | 17.15 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Enclosure | Frame | Full Load Amps | HP | kW | Mounting | Orientation | Rotation | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048S17D2017 | DP | 48 | 3.6 | 1/6 | 0.13 | Resilient Base | Horizontal | SELECTIVE CCW | €246.89 | |
 |
5KH39QN5512T | Open | 48Y | 5.1 | 1/4 | - | RB | Horizontal or Vertical | Counterclockwise | €208.39 | |
 |
5KH32FN3083 | DP | 48Z | 5.1 | 1/4 | - | RB | Horizontal or Vertical | Counterclockwise | €251.78 | |
 |
5KH32HN5620T | Open | 48Y | 6.6 | 1/3 | - | RB | Horizontal or Vertical | Clockwise | €242.61 | |
 |
5KH35MNA519T | Open | 48Y | 7.9 | 1/2 | - | RB | Horizontal or Vertical | Clockwise | €326.94 | |
 |
5KH32JN3128 | DP | 48Z | 6.2 | 1/3 | - | RB | Horizontal or Vertical | Counterclockwise | €290.28 | |
 |
056S17D2050 | DP | 56 | 7.2 | 1/2 | 0.37 | Resilient Base | Horizontal | SELECTIVE CCW | €347.72 |
