LEESON 056C17G5315 G651 / 56C17G5315K Explosion Proof Motor, 0.33 HP, 1 Phase, 60 Hz, 115/230 V, 1800 RPM
Get it by Tuesday, Oct 1
€829.89 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | Hazardous Location Motor |
| Bearings | Ball |
| Duty | Continuous |
| Efficiency Group | Standard |
| Frame | 56 |
| Frame Material | Rolled Steel |
| Full Load Amps | 6.6/3.1-3.3 |
| Hazardous Location Class | 1 C,D / 2 F,G |
| HP | 1/3 |
| Hz | 60 |
| Insulation Class | B |
| Lead Length | 8" to 18" |
| Length Less Shaft | 11.437" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | Hazardous Locations |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Hazardous Location |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | Auto |
| Nameplate RPM | 1725 |
| NEMA Design | None |
| Nominal Efficiency | 55% |
| Overall Length | 13.437" |
| Phase | 1 |
| RPM Range | 1701-1800 |
| Service Factor | 1.00 |
| Shaft Dia. | 5/8" |
| Shaft Length | 2" |
| Temp. Code | T3B |
| Thermal Protection | Auto |
| Voltage | 115/208-230 |
| Ship weight (kg) | 12.15 |
| Ship height (cm) | 20.62 |
| Ship length (cm) | 41.61 |
| Ship width (cm) | 26.67 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Length Less Shaft | Nameplate RPM | Nominal Efficiency | Overall Length | RPM Range | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
056B11G5301 | 9.6/4.7-4.8 | 1/2 | 12 15/16" | 1140 | 62% | 14 15/16" | 1101-1200 | €1,205.72 | |
 |
056C11G5306 | 6.8/3.1-3.4 | 1/4 | 11 15/16" | 1140 | 47.5% | 13 15/16" | 1101-1200 | €974.11 | |
 |
056C11G5307 | 7.8/3.6-3.9 | 1/3 | 11 15/16" | 1140 | 52.5% | 13 15/16" | 1101-1200 | €1,045.00 | |
 |
056C17E5314 | 4.8/2.3-2.4 | 1/4 | 10" | 1725 | 59.5% | 12" | 1701-1800 | €727.22 | |
 |
056C17G5317 | 11.0/5.4-5.5 | 3/4 | 12.437" | 1725 | 70% | 14.437" | 1701-1800 | €1,019.94 | |
 |
056C17G5318 | 13.4/6.8-6.7 | 1 | 12.437" | 1725 | 72% | 14.437" | 1701-1800 | €1,327.78 |
