LEESON 056C34D2109 O211 / 56C34D2109F Fan and Blower Motor, 0.33 HP, 1 Phase, 60 Hz, 115/208-230V, 3600 RPM
Get it by Tuesday, Oct 1
€262.78 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
Item | Oil Burner Motor |
Ambient (C) | 40 |
Assembly | F1 ONLY |
Duty | Continuous |
Efficiency | 64 % |
Enclosure | DP |
Frame | 56C |
Full Load Amps | 5.6/2.7-2.8 |
HP | 1/3 |
Hz | 60 |
Insulation Class | B |
kW | 0.246 |
Mounting | C-Face Footless |
NEMA Design | NO DESIGN CODE |
Orientation | Horizontal |
Phase | 1 |
Rotation | SELECTIVE CCW |
RPM | 3600 |
Service Factor | 1.75 |
Thermal Protection | Manual Protector |
Voltage | 115/208-230 |
Ship weight (kg) | 6.3 |
Ship height (cm) | 25.4 |
Ship length (cm) | 34.29 |
Ship width (cm) | 22.86 |
HS code | 8501404040 |
Country of Origin | MX |
Product | Model | Body Dia. | Enclosure | Full Load Amps | HP | kW | Motor Mounting Position | Mounting | NEMA Design | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
5KC39RN44X | 5.66" | Open Dripproof | 13.2/6.5-6.6 | 1 | - | Horizontal | Face | - | €364.84 | ||
5KC49TN2141X | 6.42" | Open Dripproof | 21.2/11.5-10.6 | 2 | - | All Angle | Face | - | €614.78 | ||
5KCR48TN2142T | 6.42" | Open Dripproof | 29.4/14.7 | 3 | - | All Angle | Face | - | €977.77 | ||
5KC36JN268X | 5.625" | - | 7.6/3.8 | 1/2 | - | Horizontal | - | - | €276.22 | ||
5KC37FN71X | 5.625" | - | 6.4/3.2 | 1/3 | - | Horizontal | - | - | €252.39 | ||
056C34D2105 | - | DP | 12/6.2-6 | 1 | 0.75 | - | C-Face Footless | DEFINITE DUTY | €375.83 | ||
056S34D93 | - | DP | 5.5 | 1/3 | 0.25 | - | C-Face Footless | NO DESIGN CODE | €76.87 |
