LEESON 056T17D5332 G127 / 56T17D5332B Fan/Blower Motor, 2/1.50 HP, 3 Phase, 60/50 Hz, 208-230/460 and 190/380V, 1800 RPM
Get it by Tuesday, Oct 1
€593.39 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 40 |
| Assembly | F1 ONLY |
| Duty | Continuous |
| Efficiency | N/A % |
| Enclosure | DP |
| Frame | 56H |
| Full Load Amps | 6.2-6.2/3.1 |
| HP | 2 |
| Hz | 60 |
| Insulation Class | B |
| kW | 1.49 |
| Mounting | Resilient Base |
| NEMA Design | B |
| Orientation | Horizontal |
| Phase | 3 |
| RPM | 1800 |
| Service Factor | 1.15 |
| Voltage | 208-230/460 |
| Ship weight (kg) | 15.3 |
| Ship height (cm) | 19.69 |
| Ship length (cm) | 33.66 |
| Ship width (cm) | 20.32 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Hz | kW | Mounting | Orientation | RPM | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5K49PN4088X | 56H | 5.1-5.2/2.6 | 1.5 | 60 | - | RB | Horizontal or Vertical | 1725 | €616.62 | |
 |
5K49UN4086X | 56H | 6.2-6.0/3.0 | 2 | 60 | - | RB | Horizontal or Vertical | 1725 | €672.22 | |
 |
5K46KN4085 | 56 | 3.3-3.0/1.5 | 3/4 | 50/60 | - | RB | Horizontal or Vertical | 1725/1425 | €478.51 | |
 |
056T17D5350 | 56HZ | 9.2-8.6/4.3 | 3 | 60 | 2.24 | Resilient Base | Horizontal | 1800 | €748.01 | |
 |
056T17D2104 | 56 | 1.5-1.6/.8 | 1/3 | 60 | 0.25 | Resilient Base | Horizontal | 1800 | €456.50 | |
 |
5K49PN3052 | 56 | 1.3/0.7 | 3.25 | 60 | - | RB | Horizontal or Vertical | 1725/1140 | €741.27 | |
 |
056T17D2101 | 56 | 3.4-3.4/1.7 | 1 | 60 | 0.75 | Resilient Base | Horizontal | 1800 | €565.89 |
