LEESON 056T17D5346 G141 / 56T17D5346B Fan/Blower Motor, 0.75/0.50 HP, 3 Phase, 60/50 Hz, 208-230/460V, 1800 RPM
Get it by Tuesday, Oct 8
€576.28 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 8
Payment Methods
Item | HVAC Motor |
Ambient (C) | 40 |
Assembly | F1 ONLY |
Duty | Continuous |
Efficiency | N/A % |
Enclosure | DP |
Frame | 56 |
Full Load Amps | 2.9-3/1.5 |
HP | 3/4 |
Hz | 60 |
Insulation Class | B |
kW | 0.56 |
Mounting | Resilient Base |
NEMA Design | B |
Orientation | Horizontal |
Phase | 3 |
RPM | 1800 |
Service Factor | 1.25 |
Thermal Protection | Automatic Protector |
Voltage | 208-230/460 |
Ship weight (kg) | 10.35 |
Ship height (cm) | 19.69 |
Ship length (cm) | 33.66 |
Ship width (cm) | 20.32 |
HS code | 8501514040 |
Country of Origin | MX |
Product | Model | Frame | Full Load Amps | HP | Hz | kW | Mounting | Orientation | RPM | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
5K49PN4088X | 56H | 5.1-5.2/2.6 | 1.5 | 60 | - | RB | Horizontal or Vertical | 1725 | €616.62 | ||
5K49UN4086X | 56H | 6.2-6.0/3.0 | 2 | 60 | - | RB | Horizontal or Vertical | 1725 | €672.22 | ||
5K46KN4085 | 56 | 3.3-3.0/1.5 | 3/4 | 50/60 | - | RB | Horizontal or Vertical | 1725/1425 | €478.51 | ||
056T17D5350 | 56HZ | 9.2-8.6/4.3 | 3 | 60 | 2.24 | Resilient Base | Horizontal | 1800 | €748.01 | ||
056T17D2104 | 56 | 1.5-1.6/.8 | 1/3 | 60 | 0.25 | Resilient Base | Horizontal | 1800 | €456.50 | ||
5K49PN3052 | 56 | 1.3/0.7 | 3.25 | 60 | - | RB | Horizontal or Vertical | 1725/1140 | €741.27 | ||
056T17D2101 | 56 | 3.4-3.4/1.7 | 1 | 60 | 0.75 | Resilient Base | Horizontal | 1800 | €565.89 |
