LEESON 145THTN6046 Y551 / 145THTN6046BA Inverter Duty Speed Ratio Motor, 2 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Oct 1
€1,374.09 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
Item | Vector Motor |
Ambient Temp. Range | 40 Degrees C |
Base | Rigid |
Bearings | Ball |
Duty | Continuous |
Efficiency Group | Epact |
Enclosure | Totally Enclosed Nonventilated |
Encoder Acceptable | Yes |
Encoder Shaft | 5/8 x 1-3/4" |
Finish | Black |
Frame | 145TC |
Frame Material | Cast Iron |
Full Load Amps | 6.0/3.0 |
HP | 2 |
Hz | 60 |
Insulation Class | F |
Insulation Feature | Patented MAX GUARD |
Max. Operating Frequency | 120 Hz |
Max. Speed | 5400 RPM |
Motor Application | Cranes |
Motor Design | 3-Phase |
Motor Enclosure Design | Totally Enclosed Nonventilated |
Motor Mounting Position | All Angle |
Motor Mounting Type | Face/Base |
Motor Shaft Design | Keyed |
Motor Shaft Rotation | CW/CCW |
Motor Thermal Protection | T-stat |
Motor Type | 3-Phase |
Mounting | Face/Base |
Mounting Position | Horizontal or Vertical |
Nameplate RPM | 1750 |
NEMA Design | A |
Nominal Efficiency | 0.855 |
Overall Length | 14 11/16" |
Phase | 3 |
Rotation | CW/CCW |
RPM Range | 1701-1800 |
Service Factor | 1.0 |
Shaft Dia. | 7/8" |
Shaft Length | 2.125" |
Speed Range | 1000:1 CT |
Thermal Protection | T-Stats |
Torque | 6.0 lb.-ft. |
Voltage | 230/460 |
Warranty | 3 yr. |
Ship weight (kg) | 38.25 |
Ship height (cm) | 23.83 |
Ship length (cm) | 40.18 |
Ship width (cm) | 31.9 |
HS code | 8501524000 |
Country of Origin | MX |
Product | Model | Enclosure | Frame | Frame Material | Full Load Amps | HP | kW | Motor Mounting Position | Mounting | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
145THTN6060 | Totally Enclosed Nonventilated | 145TC | Cast Iron | 2.4 | 2 | - | Horizontal | Face/Base | €1,489.01 | ||
143THTR5326 | Totally Enclosed Nonventilated | 143TC | Rolled Steel | 3.0/1.5 | 1 | - | All Angle | Face/Base | €887.87 | ||
145THTR5376 | Totally Enclosed Nonventilated | 145TC | Rolled Steel | 3.8/1.9 | 1 | - | All Angle | Face/Base | €1,028.52 | ||
145THTR5326 | Totally Enclosed Nonventilated | 145TC | Rolled Steel | 4.8/2.4 | 1.5 | - | All Angle | Face/Base | €1,078.17 | ||
056H17T5301 | TENV | 56C | - | 1.6/.8 | 1/2 | 0.37 | - | C-Face - Removable Base | €668.46 | ||
145THTR16032 | TENV | 145TC | - | 6/3 | 2 | 1.49 | - | C-Face Rigid | €1,387.88 | ||
056H17T5302 | TENV | 56C | - | 3/1.5 | 1 | 0.75 | - | C-Face - Removable Base | €863.98 |
