LEESON 145THTN8043 Y987 / 145THTN8043AA Inverter Duty Brake Motor, 2 HP, 3 Phase, 60 Hz, 230/460 V, 1800 RPM
Get it by Tuesday, Oct 1
€2,785.94 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | Vector Motor |
| Ambient Temp. Range | 40 Degrees C |
| Base | Rigid |
| Bearings | Ball |
| Duty | Continuous |
| Efficiency Group | Epact |
| Encoder Acceptable | Yes |
| Encoder Shaft | 5/8" x 2-1/16" |
| Finish | Blue Enamel |
| Frame | 145TC |
| Frame Material | Cast Iron |
| Full Load Amps | 6.0/3.0 |
| HP | 2 |
| Hz | 60 |
| Insulation Class | F |
| Insulation Feature | Class F |
| Max. Operating Frequency | 120 Hz |
| Max. Speed | 5400 RPM |
| Motor Application | Cranes |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Nonventilated |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Face/Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | T-stat |
| Nameplate RPM | 1750 |
| NEMA Design | A |
| Nominal Efficiency | 85.5 |
| Overall Length | 18" |
| Phase | 3 |
| RPM Range | 1701-1800 |
| Service Factor | 1.00 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2.125" |
| Speed Range | 2000:1 CT |
| Thermal Protection | T-stat |
| Torque | 10 lb.-ft. |
| Voltage | 230/460 |
| Warranty | 3 yr. |
| Ship weight (kg) | 37.35 |
| Ship height (cm) | 32.05 |
| Ship length (cm) | 50.01 |
| Ship width (cm) | 31.27 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Efficiency Group | Frame | Full Load Amps | HP | Nameplate RPM | Overall Length | Torque | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
 |
143THTN8036 | Premium | 143TC | 3.0/1.5 | 1 | 1756 | 17" | 6 lb.-ft. | €2,500.65 |
