| Item | HVAC Motor |
| Bearings | Ball |
| Capacitor Required | Yes |
| Duty | Continuous |
| Efficiency Group | Standard |
| Frame | 48 |
| Frame Material | Rolled Steel |
| Full Load Amps | 6.0/3.2-3.0 |
| HP | 1/3 |
| Hz | 50/60 |
| Insulation Class | B |
| Inverter Rated | No |
| Length Less Shaft | 8.5" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Cradle Base |
| Motor Shaft Design | Flat |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting | Cradle Base |
| Nameplate RPM | 1725/1425 |
| Nominal Efficiency | 59.5% |
| Number of Speeds | 1 |
| Overall Length | 10" |
| Phase | 1 |
| Rotation | CW/CCW |
| RPM Group | 1701-1800 |
| RPM Range | 1701-1800 |
| Service Factor | 1.35 |
| Shaft Dia. | 1/2" |
| Shaft Length | 1.5" |
| Voltage | 115/208-230 |
| Warranty | 1 Years |
| Ship weight (kg) | 8.1 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 32.08 |
| Ship width (cm) | 17.63 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame | Frame Material | Full Load Amps | HP | Hz | Length Less Shaft | Motor Design | Motor Mounting Position | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR49PN0098X | 56 | Steel | 9.0-8.8/4.5-4.4 | 3/4 | 50/60 | - | Capacitor-Start/Capacitor-Run | All Angle | €816.44 | |
 |
5KC48UN6052 | 56 | Rolled Steel | 9.4/4.7 | 1/2 | 60 | - | Capacitor-Start | - | €920.95 | |
 |
5KC36LN26X | 48 | Rolled Steel | 6.0/3.2-3.0 | 1/3 | 50/60 | 8.5" | Capacitor-Start | Horizontal | €465.05 | |
 |
5KC46JN0002X | 56 | Rolled Steel | 11.4/5.6-5.7 | 3/4 | 60 | 9" | Capacitor-Start | Horizontal | €574.45 | |
 |
5KC49PN6051 | 56 | Rolled Steel | 8.6/4.3 | 1/3 | 60 | 9.437" | Capacitor-Start | Horizontal | €645.33 | |
 |
5KC49PN6051X | 56 | Rolled Steel | 8.6/4.3 | 1/3 | 60 | 9.437" | Capacitor-Start | Horizontal | €663.67 | |
 |
5KC35JN7X | 48 | Rolled Steel | 5.2/2.6 | 1/4 | 60 | 8 1/16" | Capacitor-Start | Horizontal | €298.83 |
