LEESON 5KCP49WN9813S P180 Condenser Fan Motor, 1 HP, 1 Phase, 60 Hz, 200-230/460V, 900 RPM
Get it by Monday, Sep 30
€189.94 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Monday, Sep 30
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 40 |
| Duty | Continuous |
| Enclosure | DP |
| Frame | 56Z |
| Full Load Amps | 6.3-6.4/3.2 |
| HP | 1 |
| Hz | 60 |
| Insulation Class | B |
| Mounting | RR |
| Orientation | Horizontal or Vertical |
| Phase | 1 |
| Rotation | Select Counter clockwise |
| RPM | 825 |
| Service Factor | 1.0 |
| Thermal Protection | Automatic |
| Voltage | 200-230/460 |
| Ship weight (kg) | 17.55 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 44.93 |
| Ship width (cm) | 19.53 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Full Load Amps | HP | Rotation | RPM | Voltage | Price | |
|---|---|---|---|---|---|---|---|---|
 |
5KCP49UN9811S | 5.8-5.6 | 3/4 | Select Clockwise | 825 | 208-230 | €179.52 | |
 |
5KCP49PN9812S | 6.2/3.8-3.1 | 1/2 | Select Counter clockwise | 825 | 115/208-230 | €622.12 | |
 |
5KCP49UN9613S | 6.3-5.0/2.5 | 1 | Select Counter clockwise | 1075 | 208-230/460 | €832.94 | |
 |
5KCP49UN9614S | 4.8-5.0 | 1 | Select Counter clockwise | 1075 | 200-230 | €174.38 |
