OTC TOOLS 51683A Double Acting Hydraulic Cylinder, Stroke Length 1 Inch, 100 Tons
Get it by Tuesday, Oct 1
€12,503.56 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
Item | Hydraulic Cylinder |
Body Material | Steel |
Bolt Circle Dia. | 3.5" |
Center Hole Dia. | 3-1/2" |
Collar Thread Size | 6-7/8"-12 |
Cylinder Type | General Purpose |
Effective Area | 3.14 sq. in. |
Extended Height | 21.00" |
Handle | No |
Max. Pressure | 10,000 psi |
Oil Capacity | 143.82 cu. In. |
Outside Dia. | 7" |
Plunger Dia. | 1" |
Plunger Thread Size | 1"-8 |
Retracted Height | 21" |
Single Acting/Double Acting | Double Acting |
Stroke Length | 1" |
Thread Size | 13-9/64"-12 |
Weight Capacity | 100 ton. |
Ship weight (kg) | 81.11 |
