LEESON 056C17D2060 S114 / 56C17D2060M General Purpose Motor, 0.75 HP, 1 Phase, 60 Hz, 115/230V, 1800 RPM
Get it by Tuesday, Oct 1
€413.73 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
Item | HVAC Motor |
Bearings | Ball |
Duty | Continuous |
Frame | 56 |
Frame Material | Rolled Steel |
Full Load Amps | 10.4/5.2 |
HP | 3/4 |
Hz | 60 |
Insulation Class | B |
Length Less Shaft | 10" |
Max. Ambient Temp. | 40 Degrees C |
Motor Application | General Application |
Motor Design | Capacitor-Start |
Motor Enclosure Design | Open Dripproof |
Motor Mounting Type | Cradle Base |
Motor Shaft Rotation | CW/CCW |
Motor Thermal Protection | None |
Nameplate RPM | 1725 |
Nominal Efficiency | 70 |
Phase | 1 |
RPM Group | 1701-1800 |
RPM Range | 1701-1800 |
Service Factor | 1.00 |
Shaft Dia. | 5/8" |
Shaft Length | 2" |
Voltage | 115/230 |
Ship weight (kg) | 11.25 |
Ship height (cm) | 22.23 |
Ship length (cm) | 34.93 |
Ship width (cm) | 20.02 |
HS code | 8501404040 |
Country of Origin | MX |
Product | Model | Frame | Full Load Amps | HP | Length Less Shaft | Motor Design | Nominal Efficiency | Shaft Dia. | Shaft Length | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
048C17D2028 | 48 | 7.0/3.5 | 1/3 | 7.75" | Capacitor-Start | 57.5 | 1/2" | 1.5" | €282.94 | ||
048C17D2029 | 48 | 7.0/3.5 | 1/3 | 7.75" | Capacitor-Start | 57.5 | 1/2" | 1.5" | €373.39 | ||
048S17D2105 | 48Y | 6.6 | 1/3 | 7.75" | Split-Phase | 57.5 | 1/2" | 2" | €246.89 | ||
048S17D2106 | 48Z | 9.2 | 1/2 | 8.25" | Split-Phase | 59.5 | 1/2" | 2" | €271.95 | ||
056C17D2061 | 56 | 10.4/5.2 | 3/4 | 10" | Capacitor-Start | 70 | 5/8" | 2" | €429.62 | ||
056C17D2097 | 56 | 9.0/4.5 | 1/2 | 8.25" | Capacitor-Start | 59.5 | 5/8" | 1.875" | €348.33 | ||
056C17D2099 | 56Z | 9.0/4.5 | 1/2 | 8.25" | Capacitor-Start | 59.5 | 5/8" | 2" | €359.94 |
