| Item | HVAC Motor |
| Bearings | Ball |
| Duty | Continuous |
| Frame | 56 |
| Frame Material | Rolled Steel |
| Full Load Amps | 9.0/4.5 |
| HP | 1/2 |
| Hz | 60 |
| Insulation Class | B |
| Length Less Shaft | 8.25" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Open Dripproof |
| Motor Mounting Type | Cradle Base |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Nameplate RPM | 1725 |
| Nominal Efficiency | 59.5 |
| Phase | 1 |
| RPM Group | 1701-1800 |
| RPM Range | 1701-1800 |
| Service Factor | 1.00 |
| Shaft Dia. | 5/8" |
| Shaft Length | 1.875" |
| Voltage | 115/230 |
| Ship weight (kg) | 8.55 |
| Ship height (cm) | 20.47 |
| Ship length (cm) | 31.6 |
| Ship width (cm) | 23.19 |
| HS code | 8501404040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Length Less Shaft | Motor Design | Nominal Efficiency | Shaft Dia. | Shaft Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
048C17D2028 | 48 | 7.0/3.5 | 1/3 | 7.75" | Capacitor-Start | 57.5 | 1/2" | 1.5" | €282.94 | |
 |
048C17D2029 | 48 | 7.0/3.5 | 1/3 | 7.75" | Capacitor-Start | 57.5 | 1/2" | 1.5" | €373.39 | |
 |
048S17D2105 | 48Y | 6.6 | 1/3 | 7.75" | Split-Phase | 57.5 | 1/2" | 2" | €246.89 | |
 |
048S17D2106 | 48Z | 9.2 | 1/2 | 8.25" | Split-Phase | 59.5 | 1/2" | 2" | €271.95 | |
 |
056C17D2060 | 56 | 10.4/5.2 | 3/4 | 10" | Capacitor-Start | 70 | 5/8" | 2" | €413.73 | |
 |
056C17D2061 | 56 | 10.4/5.2 | 3/4 | 10" | Capacitor-Start | 70 | 5/8" | 2" | €429.62 | |
 |
056C17D2099 | 56Z | 9.0/4.5 | 1/2 | 8.25" | Capacitor-Start | 59.5 | 5/8" | 2" | €359.94 |
