LEESON 056H17F2021 Y364 / 56H17F2021A Inverter Duty Speed Ratio Motor, 1 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Oct 1
€694.83 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
Item | Vector Motor |
Ambient (C) | 40 |
Assembly | F3 |
Duty | Continuous |
Efficiency | 78.5 % |
Enclosure | TEFC |
Frame | 56C |
Full Load Amps | 3.2/1.6 |
HP | 1 |
Hz | 60 |
Insulation Class | H |
kW | 0.75 |
Mounting | C-Face Rigid |
NEMA Design | A |
Orientation | Horizontal |
Phase | 3 |
RPM | 1800 |
Service Factor | 1.0 |
Voltage | 230/460 |
Ship weight (kg) | 12.15 |
Ship height (cm) | 22.23 |
Ship length (cm) | 34.93 |
Ship width (cm) | 20.02 |
HS code | 8501516040 |
Country of Origin | MX |
Product | Model | Assembly | Efficiency Group | Enclosure | Frame | Full Load Amps | HP | kW | Max. Speed | Price | |
---|---|---|---|---|---|---|---|---|---|---|---|
145THTR5329 | - | Epact | Totally Enclosed Nonventilated | 145TC | 4.8/2.4 | 1.5 | - | 5400 RPM | €863.98 | ||
145THFR5329 | - | Standard | Totally Enclosed Fan-Cooled | 145TC | 5.8/2.9 | 2 | - | 4000 RPM | €1,147.08 | ||
056H17T2017 | F3 | - | TENV | 56C | 1.8/.9 | 1/2 | 0.37 | - | €499.11 | ||
056H17F2022 | F3 | - | TEFC | 56C | 3.2/1.6 | 1 | 0.75 | - | €694.83 | ||
056H17T2011 | F1 ONLY | - | TENV | 56C | 1.0 | 1/4 | 0.19 | - | €394.34 | ||
056H17F2018 | F3 | - | TEFC | 56C | 2.8/1.4 | 3/4 | 0.56 | - | €616.74 | ||
056H17T2013 | F1 ONLY | - | TENV | 56C | 1.2 | 1/3 | 0.246 | - | €447.94 |
