LEESON 145THTR5329 Y366 / 145THTR5329AA Inverter Duty Speed Ratio Motor, 1.50 HP, 3 Phase, 60 Hz, 230/460V, 1800 RPM
Get it by Tuesday, Oct 1
€863.98 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Tuesday, Oct 1
Payment Methods
| Item | Vector Motor |
| Ambient Temp. Range | 40 Degrees C |
| Base | Removable |
| Bearings | Ball |
| Duty | Continuous |
| Efficiency Group | Epact |
| Enclosure | Totally Enclosed Nonventilated |
| Encoder Acceptable | No |
| Finish | Black |
| Frame | 145TC |
| Frame Material | Rolled Steel |
| Full Load Amps | 4.8/2.4 |
| HP | 1.5 |
| Hz | 60 |
| Insulation Class | H |
| Insulation Feature | Patented MAX GUARD |
| Max. Operating Frequency | 120 Hz |
| Max. Speed | 5400 RPM |
| Motor Application | Cranes |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Nonventilated |
| Motor Mounting Position | All Angle |
| Motor Mounting Type | Face/Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Motor Type | 3-Phase |
| Mounting | Face/Base |
| Mounting Position | Horizontal or Vertical |
| Nameplate RPM | 1755 |
| NEMA Design | A |
| Nominal Efficiency | 0.855 |
| Overall Length | 13.5" |
| Phase | 3 |
| Rotation | CW/CCW |
| RPM Range | 1701-1800 |
| Service Factor | 1.0 |
| Shaft Dia. | 7/8" |
| Shaft Length | 2.125" |
| Speed Range | 1000:1 CT |
| Thermal Protection | None |
| Torque | 4.5 lb.-ft. |
| Voltage | 230/460 |
| Warranty | 3 yr. |
| Ship weight (kg) | 22.05 |
| Ship height (cm) | 23.83 |
| Ship length (cm) | 40.18 |
| Ship width (cm) | 31.9 |
| HS code | 8501524000 |
| Country of Origin | MX |
| Product | Model | Assembly | Efficiency Group | Enclosure | Frame | Full Load Amps | HP | kW | Max. Speed | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
145THFR5329 | - | Standard | Totally Enclosed Fan-Cooled | 145TC | 5.8/2.9 | 2 | - | 4000 RPM | €1,147.08 | |
 |
056H17F2021 | F3 | - | TEFC | 56C | 3.2/1.6 | 1 | 0.75 | - | €694.83 | |
 |
056H17T2017 | F3 | - | TENV | 56C | 1.8/.9 | 1/2 | 0.37 | - | €499.11 | |
 |
056H17F2022 | F3 | - | TEFC | 56C | 3.2/1.6 | 1 | 0.75 | - | €694.83 | |
 |
056H17T2011 | F1 ONLY | - | TENV | 56C | 1.0 | 1/4 | 0.19 | - | €394.34 | |
 |
056H17F2018 | F3 | - | TEFC | 56C | 2.8/1.4 | 3/4 | 0.56 | - | €616.74 | |
 |
056H17T2013 | F1 ONLY | - | TENV | 56C | 1.2 | 1/3 | 0.246 | - | €447.94 |
