LEESON 5KH39QN9541T 4338 / 5KH39QN9541AT Fan and Blower Motor, 0.75 HP, 1 Phase, 60 Hz, 115V, 1800 RPM
Get it by Monday, Sep 30
€448.56 /unit
Add To Cart
Request a Quote
Payment Methods
Get it by Monday, Sep 30
Payment Methods
| Item | HVAC Motor |
| Ambient (C) | 40 |
| Duty | Continuous |
| Enclosure | DP |
| Frame | 56 |
| Full Load Amps | 11.4 |
| HP | 3/4 |
| Hz | 60 |
| Insulation Class | B |
| Mounting | RB |
| Orientation | Horizontal or Vertical |
| Phase | 1 |
| Rotation | Counterclockwise |
| RPM | 1725 |
| Service Factor | 1.0 |
| Thermal Protection | Automatic |
| Voltage | 115 |
| Ship weight (kg) | 9.45 |
| Ship height (cm) | 19.05 |
| Ship length (cm) | 34.77 |
| Ship width (cm) | 18.11 |
| Country of Origin | MX |
| Product | Model | Frame | Frame Material | Full Load Amps | HP | Hz | Length Less Shaft | Motor Design | Motor Mounting Position | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
5KCR49PN0098X | 56 | Steel | 9.0-8.8/4.5-4.4 | 3/4 | 50/60 | - | Capacitor-Start/Capacitor-Run | All Angle | €816.44 | |
 |
5KC48UN6052 | 56 | Rolled Steel | 9.4/4.7 | 1/2 | 60 | - | Capacitor-Start | - | €920.95 | |
 |
5KC36LN26 | 48 | Rolled Steel | 6.0/3.2-3.0 | 1/3 | 50/60 | 8.5" | Capacitor-Start | Horizontal | €862.27 | |
 |
5KC36LN26X | 48 | Rolled Steel | 6.0/3.2-3.0 | 1/3 | 50/60 | 8.5" | Capacitor-Start | Horizontal | €465.05 | |
 |
5KC46JN0002X | 56 | Rolled Steel | 11.4/5.6-5.7 | 3/4 | 60 | 9" | Capacitor-Start | Horizontal | €574.45 | |
 |
5KC49PN6051 | 56 | Rolled Steel | 8.6/4.3 | 1/3 | 60 | 9.437" | Capacitor-Start | Horizontal | €645.33 | |
 |
5KC49PN6051X | 56 | Rolled Steel | 8.6/4.3 | 1/3 | 60 | 9.437" | Capacitor-Start | Horizontal | €663.67 |
